from svg_compression import *
comp_instance = Compress("test/test_vector.svg")
comp_instance.find_paths()                        # Extract path coordinates
comp_instance.linearize_paths(curve_fidelity = 10)     # Convert paths into polygons
#comp_instance.write(outputfile = "hrv.svg")
#print(comp_instance.linear_coords[0])
for path in comp_instance.linear_coords:
        p = path[0]
        print("g0 x%s y%s"%(str(p[0]),str(p[1])))
        for p in path:
                print("g1 x%s y%s"%(str(p[0]),str(p[1])))

import numpy
import svg.path
import lxml.etree as ET

'''
Compress svg figure through a variety of methods
Written July 22, 2014
Author: Gen Del Raye
'''

class SVGcode:

	def __init__(self, svg_file):
		'''
		Read svg from path 'svg_file' (e.g. 'test/test_vector.svg')
		'''
		#self.filename, self.extension = svg_file.split('.') # Get filename and extension
		#assert self.extension == 'svg', 'File must be an svg'
		try:
			self.figure_data = ET.parse(svg_file) # Parse svg data as xml
		except ET.XMLSyntaxError, e:
			'''
			Large svgs may trigger lxml's 'excessive depth in document' exception
			'''
			warnings.warn('lxml error: %s - Trying huge xml parser' %(e.message))
			huge_parser = ET.XMLParser(huge_tree = True)
			self.figure_data = ET.parse(svg_file, parser = huge_parser)
		self.root = self.figure_data.getroot() # Root object in svg

	def find_paths(self):
		'''
		Find and parse nodes in the xml that correspond to paths in the svg
		'''
		tag_prefix = '{*}'
		self.path_nodes = self.root.findall('.//%spath' %(tag_prefix))
		self.paths = list()
		self.paths = [svg.path.parse_path(p.attrib.get('d', 'M 0,0 z')) for p in self.path_nodes]

	def linearize_paths(self, curve_fidelity = 10):
		'''
		Turn svg paths into discrete lines
		Inputs:
			curve_fidelity(int) - number of lines with which to approximate curves
				in svg. Higher values necessitates longer computation time.
		'''
		self.linear_coords = [self.linearize(p, curve_fidelity) for p in self.paths]


	def linearize_line(self, segment, n_interpolate = None):
		'''
		Turn svg line into set of coordinates by returning
		start and end coordinates of the line segment.
		n_interpolate is only used for consistency of use
		with linearize_curve()
		'''
		return numpy.array([segment.start, segment.end])

	def linearize_curve(self, segment, n_interpolate = 10):
		'''
		Estimate svg curve (e.g. Bezier, Arc, etc.) using
		a set of n discrete lines. n_interpolate sets the
		number of discrete lines per curve.
		'''
		interpolation_pts = numpy.linspace(0, 1, n_interpolate, endpoint = False)[1:]
		interpolated = numpy.zeros(n_interpolate + 1, dtype = complex)
		interpolated[0] = segment.start
		interpolated[-1] = segment.end
		for i, pt in enumerate(interpolation_pts):
				interpolated[i + 1] = segment.point(pt)
		return interpolated

	def complex2coord(self, complexnum):
		return (complexnum.real, complexnum.imag)

	def linearize(self, path, n_interpolate = 10):
		segmenttype2func = {'CubicBezier': self.linearize_curve,
				    'Line': self.linearize_line,
				    'QuadraticBezier': self.linearize_curve,
				    'Arc': self.linearize_curve}
		'''
		More sophisticated linearization option
		compared to endpts2line().
		Turn svg path into discrete coordinates
		with number of coordinates per curve set
		by n_interpolate. i.e. if n_interpolate
		is 100, each curve is approximated by
		100 discrete lines.
		'''
		segments = path._segments
		complex_coords = list()
		for segment in segments:
			# Output coordinates for each segment, minus last point (because
			# point is same as first point of next segment)
			segment_type = type(segment).__name__
			segment_linearize = segmenttype2func[segment_type]
			linearized = segment_linearize(segment, n_interpolate)
			complex_coords.extend(linearized[:-1])
		# Append last point of final segment to close the polygon
		complex_coords.append(linearized[-1])
		return [self.complex2coord(complexnum) for complexnum in complex_coords] # Output list of (x, y) tuples

from svg_gcode import *
comp_instance = SVGcode("test/test_vector.svg")
comp_instance.find_paths()                        # Extract path coordinates
comp_instance.linearize_paths(curve_fidelity = 10)     # Convert paths into polygons
#comp_instance.write(outputfile = "hrv.svg")
#print(comp_instance.linear_coords[0])
for path in comp_instance.linear_coords:
	p = path[0]
	print("g0 x%s y%s"%(str(p[0]),str(p[1])))
	for p in path:
		print("g1 x%s y%s"%(str(p[0]),str(p[1])))
	print "( ---------- cut-here ---------- )"
